IM7000 Meiji Techno Inverted Brightfield Metallurgical Microscope (japan)


The Meiji Techno IM7000 Series Inverted Brightfield Metallurgical Microscope have an ergonomic slim triangular shaped design that saves bench space to maximize efficiency and offers ultimate stability with its cast aluminum alloy frame. This is the most rugged Inverted Microscope from Japan. Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units. All of our IM7000 Series controls are ergonomically positioned to provide comfort and extended ease of use for the operator.

$USD 6,322.00 $USD 7,025.00

The Meiji Techno IM7000 Series Inverted Brightfield Metallurgical Microscope have an ergonomic slim triangular shaped design that saves bench space to maximize efficiency and offers ultimate stability with its cast aluminum alloy frame. This is the most rugged Inverted Microscope from Japan. Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units. All of our IM7000 Series controls are ergonomically positioned to provide comfort and extended ease of use for the operator.

Meiji Techno IM7000 Inverted Brightfield Metallurgical Microscope

The IM7000 Series features include

  • All models come standard with ∞ Infinity Corrected Optical objectives (F=200)
  • Viewing heads are supplied with a Siedentopf type binocular head, inclined at 30° or a trinocular Siedentopf head inclined at 45°. Interpupillary distance is adjustable from 53mm to 75mm. A graduated diopter adjustment is provided as a standard feature on the left eyetube of all units.
  • Eyepieces are SWH10X, widefield, high eye point eyepieces, F.N. 22, with a 25mm reticle mount, SWH15X, SWH20X and SWH10X-F focusing eyepieces are available as an option. Anti-reflection coated, manufactured with a large diameter lens with more optical elements and high eyepoint to reduce eye fatigue and accommodate eyeglass wearers, and come equipped with a fold-down rubber eye-guards
  • Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units. Objectives are made with extra-low-dispersion glass ans utilize new advanced multilayer ani-reflection coatings. The advanced technology used in designing and creating objectives result in an objective with a higher resolving power, higher image contrast, wider field of view, improved flatness of field, and a sharp image with a minimum of flare and ghosting. The objectives are color corrected for chromatic aberration in the red and blue regions of the spectrum and offer and exceptional flat field of view.
  • Quintuple Nosepiece , side facing, with positive precision detent, click stops
  • Plain stage 180mm (X) x 245mm (Y) dimensions
  • Optional Mechanical Stage with drop down post available, 112mm (X) x 72mm (Y) movement.
  • Focus travel, 9mm total, 1.0mm up and 8mm down, Rotation of fine focus: 0.2mm per revolution.
  • Vertical Koehler illuminator equipped with 6V 30W Halogen bulb, Variable rheostat and automatic voltage sensing power supply are incorporated as standard.
  • Cast aluminum alloy body for rigidity and exceptional stability

Includes:

IM7100: Binocular Inverted Brightfield Metallurgical Compound microscope with an integrated 6V/30W vertical Koehler Halogen illuminator with variable intensity control and automatic voltage sensing power supply provides excellent specimen illumination and contrast.  Quintuple nosepiece and auto voltage sensing power supply.  Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units.  All of our IM7000 Series controls are ergonomically positioned to provide comfort and extended ease of use for the operator. Meiji’s IM Series is well suited for examination of mounted metallurgical specimens or for routine quality inspections such as, microstructure analysis, various materials testing, QA and QC examination and photomicrography.
MA814/05: Siedentopf type binocular head – inclined at 30°, Interpupillary adjustment 53mm to 75mm graduated diopter  on left eyetube (30mm I.D. eyetubes) with depolarizer
MA817 (x 2): SWH 10X Widefield high eyepoint eyepiece, Field No. 22, (accepts 25mm diameter reticle)
MA906 (x 2): Rubber Eyeguards, foldable (paired)
MA870: Planachromat E5X, ∞ objective N.A. 0.10, W.D. 20.0mm, F.L. 40.0, ∞ Infinity Corrected
MA871: Planachromat E10X, ∞ objective N.A. 0.25,W.D. 7.48mm, F.L. 20.0, ∞ Infinity Corrected
MA872: Planachromat E20X, ∞ objective N.A. 0.40, W.D. 5.20mm, F.L. 10.0, ∞ Infinity Corrected
MA873: Planachromat E50X, ∞ objective N.A. 0.75, W.D. 0.38mm, F.L. 4.0, ∞ Infinity Corrected

Stage: 180mm (X) x 245mm (Y) Plain stage (Factory installed)
Focus Mechanism: Ergonomically low positioned, coaxial coarse and fine focus knobs with adjustable tension
Front Photo Port: Front mounted camera port suitable for CCD, 35mm SLR, or digital cameras with optional camera adapters to facilitate a wide range of camera and video equipment

MA475/05: LB100 Blue clear 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA476: G533 Green clear 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA774: ND50 Neutral density filter, 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA497: Polarizing filter, 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA809/10: Removable AC Electric cord with plug for 115V models
MA326: Halogen bulb, 6V 30W (Factory installed)
MA327: Fuse 3A, Replacement (Factory installed)
MA714: Dust cover
Manual: IM7000 Meiji Techno Instruction Manual
Warranty: Limited Lifetime Warranty Card

Product Information

Manufactured: 100% MADE IN JAPAN
Warranty: LIMITED LIFETIME WARRANTY
Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information

Weight: 36 lbs (10.5kg)
Box Size: 16 x 14 x 21 inches
Footprint: 364mm (D) x 220mm (W)
Binocular head type: 485 mm(D) x 411 mm (H) x 220 mm(W) (8.0kg)( 29.0 lbs)
Trinocular head type: 485 mm(D) x 440 mm(H) x 2210 mm(W) (8.5Kg)(31.0 lbs)
Binocular Ergonomic head type: 485 mm(D) x 440mm(H) x 2210mm(W) (8.5Kg)(31.0 lbs)

ModelHeadTypeIlluminationEyepiecesObjectivesStage
IM71000BinocularBrightfieldKoehler Vertical
6 volt 30 watt halogen
SWH10x FN22Planachromat E5X, E10X, E20X, E50X,Fixed flat-top
180mm X 245mm
IM71000EErgonomic Binocular
IM72000Ergonomic Trinocular
IM7520BinocularBrightfield/DarkfieldKoehler Vertical
12 volt 50 watt halogen
Planachromat BD E5X, BD E10X, BD E20X, BD LWD E50XFixed mechanical 224mm(x) X 174mm(y)
IM7510Ergonomic Binocular
IM7530Ergonomic Trinocular



VIEWING HEADS

The binocular model, the IM7100, incorporates the MA814 Siedentopf-type binocular head while the trinocular model, the IM7200, has the MA816/10 Siedentopf-type trinocular head. The MA816/10 uses an 80/20 beamsplitter that can be engaged for photomicroscopy. (100% to eyetubes or 80% to phototube and 20% to the eyetube.) Each microscope head has the eyetubes inclined at 30 degrees with the left eyetube having graduated diopter settings. The interpupillary distance on the viewing heads is adjustable between 53mm – 75mm. An optional ergonomic binocular head is also available.

EYEPIECES

10X Super Widefield High Eyepoint eyepieces are standard, and 15X and 20X eyepieces are also available as an option. A Super Widefield High Eyepoint 10X focusable eyepiece that accepts standard 25mm reticules is also available.</

OBJECTIVE CHANGER

The smooth-operating, ball bearing mounted, quintuple nosepiece provides effortless objective changes.

OBJECTIVES

Meiji Techno offers their newly designed E.Planachromat Infinity Corrected objectives for brightfield observation modes. Infinity tube lens: F = 200mm..

STAGE

The standard fixed plain stage measures 180mm(x) by 245mm(y). The optional attachable mechanical stage measures 112mm(x) x 71mm(y). The mechanical stage features ergonomically positioned right-handed coaxial drop down controls.

ILLUMINATION

A powerful Koehler method vertical illuminator with 6 volt 30 watt halogen bulb in an adjustable centering socket provides enhanced image quality of observations and adjustable brightness control.

PHOTOMICROGRAPHY

Meiji Techno offers a broad range of digital video cameras which offers excellent sensitivity, high resolution and a wide dynamic range for the most demanding brightfield and darkfield microscopy applications including clinical pathology and cytology, life sciences and geology. Some models has included software, that can preview and capture still shots and live videos to a PC or Mac with USB port or HDMI connectivity.

Included:

IM7100: Binocular Inverted Brightfield Metallurgical Compound microscope with an integrated 6V/30W vertical Koehler Halogen illuminator with variable intensity control and automatic voltage sensing power supply provides excellent specimen illumination and contrast.  Quintuple nosepiece and auto voltage sensing power supply.  Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units.  All of our IM7000 Series controls are ergonomically positioned to provide comfort and extended ease of use for the operator. Meiji’s IM Series is well suited for examination of mounted metallurgical specimens or for routine quality inspections such as, microstructure analysis, various materials testing, QA and QC examination and photomicrography.
MA814/05: Siedentopf type binocular head – inclined at 30°, Interpupillary adjustment 53mm to 75mm graduated diopter  on left eyetube (30mm I.D. eyetubes) with depolarizer
MA817 (x 2): SWH 10X Widefield high eyepoint eyepiece, Field No. 22, (accepts 25mm diameter reticle)
MA906 (x 2): Rubber Eyeguards, foldable (paired)
MA870: Planachromat E5X, ∞ objective N.A. 0.10, W.D. 20.0mm, F.L. 40.0, ∞ Infinity Corrected
MA871: Planachromat E10X, ∞ objective N.A. 0.25,W.D. 7.48mm, F.L. 20.0, ∞ Infinity Corrected
MA872: Planachromat E20X, ∞ objective N.A. 0.40, W.D. 5.20mm, F.L. 10.0, ∞ Infinity Corrected
MA873: Planachromat E50X, ∞ objective N.A. 0.75, W.D. 0.38mm, F.L. 4.0, ∞ Infinity Corrected

Stage: 180mm (X) x 245mm (Y) Plain stage (Factory installed)
Focus Mechanism: Ergonomically low positioned, coaxial coarse and fine focus knobs with adjustable tension
Front Photo Port : Front mounted camera port suitable for CCD, 35mm SLR, or digital cameras with optional camera adapters to facilitate a wide range of camera and video equipment

MA475/05: LB100 Blue clear 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA476: G533 Green clear 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA774: ND50 Neutral density filter, 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA497: Polarizing filter, 19.5mm diameter filter in metal mount, fits 25mm filter slot
MA809/10: Removable AC Electric cord with plug for 115V models
MA326: Halogen bulb, 6V 30W (Factory installed)
MA327: Fuse 3A, Replacement (Factory installed)
MA714: Dust cover
Manual: IM7000 Meiji Techno Instruction Manual

OPTIONAL COMPONENTS & ACCESSORIES BELOW

Viewing Heads
MA816/15: Siedentopf type trinocular head, inclined at 30°, I.P. adjustment 53mm to 75mm graduated diopter on left eyetube (30mm I.D. eyetubes) with depolarizer Includes 80/20 beamsplitter (100% to eyetubes or 80% to photo 20% to eyetube) Inverted image (Included in Model IM7200)
MA1034: Trinocular Siedentopf head, erect image, inclined at 30°, I.P. adjustment 53mm to 75mm, graduated diopter on left eyetube (30mm I.D. eyetubes) Includes 0/100 beamsplitter (100% to eyetubes or 100% to phototube)
MA957/20: Ergonomic binocular head, erect image, inclination adjustable vertically from 10° to 50° (With depolarizer)

Eyepieces
MA818: SWH 15X, widefield, high eyepoint eyepiece (each) Field No. 16 (MA818 accepts 19mm diameter reticle)
MA819: SWH 20X, widefield, high eyepoint eyepiece (each) Field No. 12 (MA819 accepts 19mm diameter reticle)
MA859: SWF 10X-F, focusing widefield, high eyepoint eyepiece (each) Field No. 22 (MA859 accepts 25mm diameter reticle)

Brightfield Objectives
MA874: Planachromat E100X ∞ objective N.A. 0.90, F.L. 2.0, W.D. 0.34

Eyepiece Micrometer
MA738: Eyepiece micrometer, for grain sizing in steel, 25mm diameter

Stages (Fixed 245mm x 180mm Stage is included with stand)
MA875: Attachable mechanical stage, 112mm (X) x 71mm (Y) movement, with drop down right hand coaxial controls (Optional) (Requires MA876 stage insert)
MA876: Metal stage plate insert for MA875 attachable mechanical stage for IM7000 Series (Circular Insert – 74.94 mm diameter black anodized ring with 63.8mm silver keyhole insert)

Bulbs and Fuses
MA326: Spare bulb 6V 30W halogen lamp (Transmitted light)
MA327: pare Fuse 3A for transmitted light halogen Illuminator
