BUM230 Biological Microscope
Introduction
With precision machining equipment and advanced alignment technology, BS-2030 series monocular, binocular and trinocular microscopes are classical biological microscope.
Features
1. New machining facility and advanced alignment technology;
2. With complete functions and outfit of binocular microscope;
3. Comfortable operation with updated and ergonomic design;
4. Compact and flexible, ideally suited for desktop, laboratory worktable;
5. Interpupillary distance can be adjusted to fit for observation.
Applications
This binocular microscope is an ideal instrument in biological, histological, pathological field and can be widely used in medical and sanitary establishments, laboratories, institutes, academic laboratories, colleges and universities.
Specifications
| model | BUM230 M | BUM230 B | BUM230 T | |
| Viewing Head | Monocular Head Inclined at 45°, 360° Rotatable | ● | ||
| Sliding Binocular Head Inclined at 45°, 360° Rotatable; 55-75mm interpupillary distance. Anti-mould. | ● | |||
| Trinocular Head, Head Binocular sliding inclined at 45 º and 360 º turn 55-75mm interpupillary distance, digital cameras can be added to the trinocular head. Anti-mould. | ● | |||
| Eyepiece | Wide Field Eyepiece WF10×/ 18 | ● | ● | ● |
| Wide Field Eyepiece WF16×/ 11 | ○ | ○ | ○ | |
| Nosepiece | Quadruple Nosepiece | ● | ● | ● |
| Quintuple Nosepiece | ○ | ○ | ○ | |
| Objective | Achromatic Objective 4×, 10×, 40×, 100× | ● | ● | ● |
| Achromatic Objective 20×, 60× | ○ | ○ | ○ | |
| Plan Achromatic Objective 4×, 10×, 20×, 40×, 60×, 100× | ○ | ○ | ○ | |
| Total magnifications | With 10x eyepiece: 40×, 100×, 400×, 1000× | ● | ● | ● |
| With 16x eyepiece: 64×, 160×, 640×, 1600× | ○ | ○ | ○ | |
| Stage | Double Layer Mechanical Stage 140×140mm/ 75×50mm | ● | ● | ● |
| Single Layer Mechanical Stage140×140mm/ 75×50mm | ○ | ○ | ○ | |
| Focus | Coaxial Coarse & Fine Adjustment, Moving Range 28mm, Fine Division 0.002mm. | ● | ● | ● |
| Condenser | Abbe NA 1.25 with Iris Diaphragm & Filter | ● | ● | ● |
| Illumination | Built-in Illumination, 6V 20W Halogen light, intensity adjustable | ● | ● | ● |
| Plan-concave Mirror | ● | ● | ● | |
| LED Illumination 3W | ○ | ○ | ○ | |
| Body / Energy | Body firm backing of Aluminum and built in power supply 110-240V | ● | ● | ● |
| Supplied with | dust cover, blue + green filter, immersion oil and halogen light source parts and operating manual | ● | ● | ● |
| Polarization Set | Simple Polarization Set | ○ | ○ | ○ |
| Phase Contrast Kit | Simple phase contrast kit | ○ | ○ | ○ |
| Sliding phase contrast kit | ○ | ○ | ○ | |
| Turret phase contrast kit | ○ | ○ | ○ | |
| Dark Field Attachment | Dark Field Attachment (Dry) NA0.9 | ○ | ○ | ○ |
| Dark Field Attachment (Oil) NA1.25-1.36 | ○ | ○ | ○ | |
| Optional | Rechargeable battery(only for LED illumination) | ○ | ○ | ○ |
| Dimension & G.W. | 33cm×28cm×44cm×, 9 kg | ● | ● | ● |
Note: ●Standard Outfit, ○ Optional
Sample Images
The following specimen images are taken with BUM230T.
Item #BS2030 M/B/T
