Premixed (5% CO2 / 95% Air) Gas Controller with humidifier

Availability:

In stock


Compare

Pre-mixed (5% CO2) Controller comes with a humidifier

In stock

$1,743.00 $2,500.00

Balanced CO2 content inside the incubator not only controls pH of cell media, but also brings the gas consumption to the minimum.

Designed for live cell imaging and time-lapsed microscopy.

The controller is used to deliver gas mixture inside any custom enclosure and  miniature incubators.

  • Designed for live cell imaging and time-lapsed microscopy.
  • The controller is used to deliver gas mixture inside any custom enclosure and  miniature incubators.
  • Connects to a cylinder with compressed pre-mixed (5%CO2/95%O2 or any other, including nitrogen and low O2) gas.
  • The output connects directly to a gas port of the incubator or a humidifier.
  • Provides 225 cm3/sec maximum gas flow, which is enough to fill 1L enclosure in less than 5 sec.
  • The controller regulates output gas pressure to provide continuous slow stream of gas mixture, to replace residual gases inside the incubator.
  • Can be used as a source of regulated pressure to saturate solutions with gases and to control flow of solutions.
  • Simple to use.
  • Can be adjusted to fill incubators of different volumes.

Gas pressure controller, PC-MI

Designed for live cell imaging and time-lapsed microscopy.The controller is used to deliver gas mixture inside any custom enclosure and  miniature incubators. Connects to a cylinder with compressed pre-mixed (5%CO2/95%O2 or any other, including nitrogen and low O2) gas. The output connects directly to a gas port of the incubator or a humidifier. Provides 225 cm3/sec maximum gas flow, which is enough to fill 1L enclosure in less than 5 sec. The controller regulates output gas pressure to provide continuous slow stream of gas mixture, to replace residual gases inside the incubator. Can be used as a source of regulated pressure to saturate solutions with gases and to control flow of solutions. Simple to use. Can be adjusted to fill incubators of different volumes. Balanced CO2 content inside the incubator not only controls pH of cell media, but also brings the gas consumption to the minimum. Click on image to enlarge. Note: if using a source of pure CO2, a different CO2-MI controller is required.

Required accessories: a source of CO2 gas, miniature incubator.

SKU: gasmixer5 Categories: , , ,
Input:Max 300PSI
Output:Max 25PSI / 225 cm3/sec gas flow
Connectors:Push-to-connect:

INPUT for 5/32in. (4mm) O.D. tubing (included);

OUTPUT for 1/8in O.D. tubing (included);

can be replaced with any 10-32 threaded connectors;

includes luer fitting for different size tubing;

includes easy-disconnect coupling for 1/4in. O.D. tubing

Indicators:Output LOW, output CLOSE
Controls:INPUT PRESSURE regulator 0-25PSI,

CLOSE switch,

CLOSE TTL input (+5V),

OUTPUT PRESSURE settings,

MANUAL dial to SET pressure,

EXTERNAL input to SET pressure,

MONITOR pressure – analog output

Dimensions:6 x 2.5 x 9in.
Power:Includes external 120/230VAC power supply

Premixed (5% CO2 / 95% Air) Gas Controller with humidifier

A humidifier CO2-500ML is included;

Heated Humidifier is included. When passed through heated water, CO2 mixture becomes humid. Can be also used as an indicator of gas flow – bubbles will indicated gas flowing inside the incubator. Connects inline between the controller and the incubator.

Required accessories: a source of CO2 gas, miniature incubator.

Optional accessories: , small volume delivery system, gas mixture adapter, pressurized cylinders.
