EM-23 Binocular Entry-Level Turret Stereo Microscope

Request a Quote

The EM-20 Series Stereo Microscopes have crisp, erect images over a wide field of view. Featuring incident and transmitted illumination, these student microscopes are built to last, year after year. Just perfect for grade schools and high schools!

Add to Wishlist
Guaranteed Safe Checkout

Questions? Request a Call Back

The EM-20 Series Stereo Microscopes have crisp, erect images over a wide field of view. Featuring incident and transmitted illumination, these student microscopes are built to last, year after year. Just perfect for grade schools and high schools!

EM-23 Binocular Entry-Level Turret Stereo Microscope

The EM-20 Series features include:

  • Turret Style Objective Changer with Triple Magnifications
  • Robust metal body with smooth rack & pinion
  • Fresh design, Ergonomic focus knobs
  • Light weight, compact body, easy to carry with hand grip
  • LED illuminators feature a long life with low power consumption
  • Transmitted and incident LED illumination equipped with variable intensity
  • Rechargeable batteries, cordlessfeature enables use of the instrument without an outlet.
  • All optical parts are anti-fungus treated
  • 2 year warranty
Model Head Body Magnification Rechargable
EM-22 Binocular Turret
1X, 2X, 3X		 10X, 20X, 30X ✔
EM-23 Turret
1X, 2X, 4X		 10X, 20X, 40X ✔

VIEWING HEADS
Binocular 45° inclined tubes, One ± 5 diopter adjustment, Interpupillary distance adjustable between 55 mm and 75 mm

EYEPIECES
Paired WF 10x/20mm eyepieces

OBJECTIVES
Revolving nosepiece with Triple 1x/2x/3x and 1x/2x/4x magnification objective with field of views of 20/10/6.7 mm and 20/10/5 mm.
Magnifications from 10x up to 20x, 30x and 40x with working distance 60 mm.

All optical parts are anti-fungus treated.

STAND
Rack and pinion design. Ergonomically designed base with 2 object clamps. Alloy metal cast, hardened off-white coated. Built-in rechargeable 1.800 mAh battery and external power supply.

FOCUSING ADJUSTMENT
Coarse adjustment with tension control.

ILLUMINATION
The 1 W transmitted and incident LED illuminators can be used simultaneously.
Both light intensities can be adjusted separately. Rechargeable batteries enable portability.
