BioScan-360 Digital Pathology/Histology/Geology Slide Scanner
$USD 2,500.00 Original price was: $USD 2,500.00.$USD 1,360.00Current price is: $USD 1,360.00.
- Low cost slide scanner for histology and optional geological slides
- Simple to use software, scans, saves in TIFF or JPEG format
- Typical scan times is just over a minute
- Included holder accepts two 1 x 3″ glass slides
- Optional GEOLOGICAL POLARIZING holder accepts one 1 x 2″ glass slide,
- 3600 dpi optical resolution & 10,000 x 10,000 dpi digital resolution, 2.54 microns per pixel
- LED white light illumination
- 24 bit color sampling
- Dynamic range 3.8
- Real time sharpening, automatic color correction
- PC Windows XP/Vista/7/8 Mac OS X 10.5/10.6/10.7/10.8
- USB2 interface
BioScan-360 / PathScan Enabler 5, Histological and Geological Slide Scanner
The Bio-Scan-360 or PathScan Enabler 5 is the latest version of the patented PathScan series digital slide scanners. The original PathScan Enabler helped create the market for personal digital slide scanning over 20 years ago. With the new intuitive design, the PathScan Enabler 5 allows scanning of whole mounted histological samples attached to standard 1 X 3 inch cover slipped glass slides. The new optional GEOLOGICAL POLARIZING holder allows scanning of polished rock thin sections attached to 1 X 2 inch glass slides in both brightfield and polarized light!
Bio-Scan-360 / PathScan Enabler 5 solves low power, large field of view, and high resolution imaging problems. Scan area is 24.3 x 36.5 mm, resulting in stunning, incredible images up to 14,320 x 9,522 pixels! The Bio-Scan-360 / PathScan Enabler 5 holds two (2) 1 X 3 inch glass slides and includes simple to use software for both Windows and Mac computers. The GEOLOGICAL POLARIZING holder accepts one (1) 1 x 2 inch glass slide. Image files are saved in TIFF or JPEG formats. The PathScan Enabler 5 is designed not to replace but complement a microscope and digital camera. The entire sample is scanned with an even, clear background and makes a perfect OVERVIEW image that can be viewed in a variety of software programs. Image scans are equivalent to 50X microscope resolution. Now in its 20th year of production, thousands are in use!
Stunning, incredible images up to 14,320 x 9,522 pixels. Now in BRIGHTFIELD and (optional) POLARIZED light!
Client’s quote:
“Conventional microscopes equipped with low power objectives and digital cameras typically cannot capture samples larger than 6 mm in diameter. The BioScan-360 captures specimens as large as 36.5 mm in diameter! Better yet, there is no uneven illumination or out of focus sample edges, as can be the case with traditional low power image capture techniques”
Feature
1.Fast and cost effective feature to digitize slide tissue sample
2.Simple operation interface with PC/MAC.
3.High Dynamic Range (3.8 OD) can easily Identify each cell individually.
4.From basic histology research to high school biology study.
5.Equivalent to 4x resolution.
6. 3600 dpi optical resolution, 10,000dpi digital resolution
Specifications
- Low cost slide scanner for histologyand optional geological slides
- Simple to use software, scans, saves in TIFF or JPEG format
- Opens image in Adobe Photoshop, Word, Excel, PowerPoint, etc.
- Typical scan times is just over a minute
- Included holder accepts two 1 x 3″ glass slides
- Optional GEOLOGICAL POLARIZING holder accepts one 1 x 2″ glass slide
- 10,000 x 10,000 dpi digital resolution, 2.54 microns per pixel
- Viewing windows allows you to see exactly what will be scanned
- LED white light illumination
- Windows and Mac compatible
- 24 bit color sampling
- Dynamic range 3.8
- Real time sharpening, automatic color correction
- PC Windows XP/Vista/7/8 Mac OS X 10.5/10.6/10.7/10.8
- USB2 interface
- Dimensions 410 x 150 x 280 mm
- Fifth generation, 1000’s sold!
Resolution | 10,000 x 10,000 dpi (digital) 3600 x3600 dpi (optical) |
Signal Expression | Color |
Dynamic Range | 3.8 |
Scanning Area | 24.3 x 36.5 mm (H x W) |
Scan medium | 75 x 25mm Slides |
Picture Format | TIFF, JPEG |
Light | Light Transmission white LED |
PC Interface | Windows XP / Vista / 7 / 8 Intel-based Mac OS X 10.5 / 10.6 / 10.7 /10.8 |
Dimensions | 410 X 150 X 280 mm (16.14 x 5.9 x 11 inch) |
Weight | 2.1KG (4.63 lb) |
Power | 100~240 AC Adapter, 12V/1.5A |
