Multi-Purpose Wings-type Tilting Microscopy Stand
This stand is multi-functional with unlimited application. It was designed for multi-purpose applications, such as lightsheet microscopy, custom stereoscope, fluorescence and metallurgical microscopes for both upright and inverted type of microscopy imaging, scanning, illuminating, etc.
Specification:
- Scope holder:Φ76mm
- Vertical Post Height:410mm
- Vertical Post Dia.:Φ37.2mm
- Horizontal Length:310mm
- Horizontal Dia.:Φ37.2mm
- Base
- Stand Throat Depth: 124mm
- Dimensions:380x395x12mm
- Horizontal Rotation Angle:360° Rotatable
- Horizontal Arm Travel Distance on Z-Axis: 260mm
- Horizontal Arm Stretch Range: 160mm
- Net weight: 26.24kg (57.85lbs)
- Dimensions: 520x560x430mm
