Square Sensor & Long Rectangular Chip Cameras


  • Full square shape or elonagated rectangular sensor with L/W ratio from 1.3 to 2.40
  • High resolution; from 1 to 45MP
  • Color or Monochrome
  • Long exposure time, up to 1 hr
  • With or without cooling
  • Great choice for microscopy, astronomy, photography, art and printing, special field of view size.

Request a Quote

Introduction

A client in biomedical field, located in Grater Chicago Area, OH, USA, called us and asked for camera and imaging system to capture images of his device which is in square shape. We also had a client, again from industrial section in biotechnology, need a camera which has a chip in a long rectangular shape to capture images of C. Elegans inside a long microfluidic channel.  Finding a camera with such a shape of chip is not difficult but it is not also listed somewhere as one ready to go. It is possible to make a square ROI, but the client did not like to loose that part of the image. Here we made a list of those cameras.





Digital Microscopy Cameras with special sensor shape for inspection

Digital microscopy cameras with square chip or long rectangular sensor are listed here to help the scientists and biomedical device engineers to find the right camera. We have listed from 4 to 16MP fully square shape chips and also stretched rectangular shape sensor cameras from 2MP to 21MP, from 1/2.3″ till 1.1″, monochrome or color, all with USB 3.0 connection.

If  you do not see the camera in the list, simply contact us. We have much more to offer.

Square Sensor Cameras

Order Code Sensor & Size (mm) Pixel (μm) G Sensitivity
Dark Signal
FPS/Resolution Binning Exposure
BIC-E3C-32C 32MP

Sony Special (C)

1.15″ (12.964×12.964)

2.315×2.315 108mv with 1/30s
0.03mv with 1/30s
[email protected]×5600

[email protected]×2800

[email protected]×1400

1×1

2×2

4×4

0.1-15mS
BIC-E3S-16C 15.6MP

Sony Special(C)
1.1″(13.0×13.0)

3.62 x 3.62 399mv with 1/30s
0.10mv with 1/30s
[email protected]×3592
[email protected]×1796
[email protected]×1316
1×1,
2×2,
3×3
0.1ms~15s
BIC-E3S-9C 9MP(C)
1.0″(11.31×11.28)
2.0 x 2.0 535mv with 1/30s
0.10mv with 1/30s
[email protected] 3000 1×1,
2×2,
3×3
0.1ms~15s
BIC-GYA-4.2 4.2MP/

GSENSE2020S

(M,RS)
1.2”(13.31×13.31)

6.5 x 6.5 8.1×10^7 (e-/((W/m2).s))
Peak QE 64.2% @595nm
[email protected]×2046
[email protected]×1023
1×1
2×2
0.01ms~60s
BIC-GYB-4.2 4.2MP

GSENSE2020BSI (M,RS )
1.2”(13.31×13.31)

6.5 x 6.5 1.1×10^8 (e-/((W/m2).s))
Peak QE 93.7% @595nm
[email protected]×2046
[email protected]×1023
1×1
2×2
0.01ms~60s
BIC-GYC-4.2 4.2MP

GSENSE2020BSI(M,RS )
1.2”(13.31×13.31)

6.5 x 6.5 1.1×10^8 (e-/((W/m2).s))
Peak QE 93.7% @595nm
[email protected]×2046(12bit)
[email protected]×1024(12bit)
1×1
2×2
0.01ms~60s
BIC-GYD-4.2 4.2MP/

GSENSE2020BSI

(M,RS )
1.2”(13.31×13.31)

6.5 x 6.5 1.1×10^7 (e-/((W/m2).s))
Peak QE 93.7% @595nm
[email protected]×2046(16bit)
[email protected]×1024 (16bit)
1×1
2×2
0.01ms~60s
BIC-GYSE-4.2 4.2MP/

GSENSE2020BSI(M,RS )
1.2”(13.31×13.31)

6.5 x 6.5 1.1×10^7 (e-/((W/m2).s))
Peak QE 93.7% @595nm
[email protected]×2046(12bit)
[email protected]×1024 (12bit)
1×1
2×2
0.01ms~60s

Long Rectangular Sensor

Order Code Sensor & Size (mm) Length per Height ratio Pixel(μm) G Sensitivity
Dark Signal
FPS/Resolution Binning Exposure
BIC-E3CL-16B 16MP

MN34230(C)
4/3“ (17.60×13.30)

1.323 3.8×3.85 R: 1315LSB
Gr: 2413LSB
Gb: 2413LSB
B: 1042LSB
22 @4648×3506
[email protected]×1750
[email protected]×1168
1×1,
2×2,
3×3
0.2ms -15s
BIC-E3CL-21 21MP

IMX269(C)
4/3″(17.40×13.00)

1.338 3.3×3.3 399mv with 1/30s
0.1mv with 1/30s
[email protected]×3954
[email protected]×3952
56 @2640×1976
[email protected]×1316
[email protected]×438
1×1,
2×2,
3×3,
9×9
0.1ms- 15s
BIC-E3CL-12 12MP

IMX304(C,GS)
1″(14.13×10.35)

1.365 3.45×3.45 1146mv with 1/30s
0.1mv with 1/30s
[email protected]×3000
[email protected]×1500
1×1 0.244ms -15s
BIC-E3C-46C 46MP

Sony Special  (C)
1.4″ (18.93×13.00)

1.456 2.315×2.315 108mv with 1/30s
0.03mv with 1/30s
[email protected]×5616

[email protected]×5556

[email protected]×2808

[email protected]×2160

[email protected]×1080

[email protected]×720

1×1

2×2

3×3

4×4

0.1-15mS
BIC-E3C-46M 46MP

Sony Special (M)
4/3″ (19.11×13.00)

1.470 2.32×2.32 351mv with 1/30s
0.12mv with 1/30s
[email protected]×5616
[email protected]×2808
1×1,
2×2
0.1ms~15s
BIC-E3CL-20 20MP

IMX183(C)
1″(13.06×8.76)

1.491 2.4×2.4 462mv with 1/30s
0.21mv with 1/30s
[email protected]×3648
50 @2736×1824
[email protected]×1216
1×1,
2×2,
3×3
0.1ms -15s
BIC-E3CL-8.3A 8.3MP

IMX274(C)
1/2.5″(6.22×3.50)

1.777 1.62×1.62 236mv with 1/30s
0.15mv with 1/30s
[email protected] 3840×2160
[email protected] 1920×1080
1×1,
2×2,
0.244ms -15s
BIC-E3CL-8.3B 8.3MP

IMX334(C)
1/1.8″(7.68×4.32)

1.778 2.0×2.0 505mv with 1/30s
0.15mv with 1/30s
[email protected] 3840×2160
[email protected] 1920×1080
1×1,
2×2,
0.02ms – 15s
BIC-E3CL-2 2.0MPI

MX385(C)
1/2″(7.20×4.05)

1.778 3.75×3.75 2350mv with 1/30s
0.15mv with 1/30s
125 @1920×1080 1×1 0.1ms – 15s
BIC-E3CL-9 9MP

IMX305(C,GS)
1″(14.13×7.45)

1.897 3.45×3.45 1146mv with 1/30s
0.15mv with 1/30s
[email protected]×2160
[email protected]×1080
1×1,
2×2,
0.1ms – 15s
BIC-E3CL-16A 16MP

MN34120(C)
1/2.13“ (6.18×14.67)

2.405 1.335×1.335 R: 2453LSB
Gr: 2444LSB
Gb: 1054LSB
B: 996LSB
16 @4648×3506
30 @2304×1750
27 @1536×1168
1×1,
2×2,
3×3
0.2ms – 2s

C: color, M: Monochrome; Note: a camera with over 1000mV G sensitivity is recommended for epi-fluorescence imaging.
