Tokai Hit (Japan) Gas Mixer


Tokai-Hit Digital Gas Mixer, CO2/O2, CO2/Air Hypoxia, Hypoxic Pre-Conditioning; O2 concentration: 1.0%-Atomospheric concentration CO2 concentration: 2.5%-20.0%

$USD 6,500.00
$USD 7,000.00

Digital Gas Mixer for stage top incubators.

Made in Japan.

Hypoxia
Hypoxic Pre-Conditioning
O<span >2 concentration: 1.0%-Atomospheric concentration
CO<span >2 concentration: 2.5%-20.0%
Creates hypoxia and normal conditions with easy settings.
Requires only CO2 and N2 cylinders, allowing safe,low oxygen environment

Basic performance specifications

Gas Concentration
O2 concentration
CO2 concentration
:1.0% – Automospheric concentration
:2.5% – 20.0%

Control Method
:PID method

Air gas flow
:0 -200ml/min

Power source
:AC100V – 240V

Maximum power consumption
:100VA

Input gas type
:100%CO2
:100%N2

Input gas pressure
:0.1MPa

Outside dimensions
:W175 x D260 x H280(mm)

Weight
:6.5kg

Adjustable CO<span >2 concentration and flow rate depending on application
<span >CO2 <span >concentration : 2.5%~20.0%
CO2 flow rate : 50ml/min~200ml/min


<span >Basic performance specifications

CO<span >2 concentration
:2.5% – 20%

Control Method
:PID method

Output gas flow
:50 – 200ml/min

Power source
:AC110V – 120V(GM-4000A)
:AC220V – 240V(GM-4000E)

Maximum power consumption
:100VA

Input gas type
:100%CO2

Input gas pressure
:0.1MPa

Outside dimensions
:W160 x D300 x H200(mm)

Weight
:5.7kg

An evolutionary step in Stage Top Incubator for Microscopes, providing optimally conditioned mixed gas during Live Cell Imaging.
For stable 5%CO<span >2 + 95% air mixed gas supply

Basic performance specifications

CO2 concentration
:5%(fixed)

Control Method
:PID method

Output gas flow
:160ml/min(fixed)

Power source
:AC110V – 120V (GM-2000A)
:AC220V – 240V(GM-2000E)

Maximum power consumption
:100VA

Input gas type
:100%CO2

Input gas pressure
:0.1MPa

Outside dimensions
:W160 x D300 x H200(mm)

Weight
:4.8kg

SKU: Gasmixers Categories: , , ,
Model GM-800 GM-4000 GM-2000
"" ""  ""
 Application Hypoxia Condition
Hypoxic Pre-Conditioning
O2 concentration: 1.0%-Atomospheric concentration
CO2 concentration: 2.5%-20.0%Creates hypoxia and normal conditions with easy settings. Requires only CO2 and N2 cylinders, allowing safe,low oxygen environment
Adjustable CO2 concentration
and flow rate depending on applicationCO2 concentration:2.5%-20.0%
CO2flow rate:50m/min〜200ml/min
An evolutionary step in Stage Top Incubator for Microscopes, providing optimally conditioned mixed gas during Live Cell Imaging.
For stable 5% CO2 + 95%Air mixed gas supply
 O2 concentration  1.0%〜Atomospheric concentration
 CO2 concentration     2.5%〜20.0%  2.5%〜20.0%  5%(fixed)
 Control method     PID method      PID method      PID method
Air gas flow /  Output gas flow  0〜200ml/min  50〜200ml/min  160ml/min(fixed)
Input gas pressure  0.1MPa  0.1MPa 0.1MPa
 Outside dimensions  W175×D260×H280  W160×D300×H200  W160×D300×H200
 Weight  6.5kg  5.7kg  4.8kg
 Power source  AC100V〜240V  AC100V〜240V  AC100V〜240V
 Maximum power consumption  100VA  100VA  100VA
Model GM-800 GM-4000 GM-2000
"" ""  ""
 Application Hypoxia Condition
Hypoxic Pre-Conditioning
O2 concentration: 1.0%-Atomospheric concentration
CO2 concentration: 2.5%-20.0%Creates hypoxia and normal conditions with easy settings. Requires only CO2 and N2 cylinders, allowing safe,low oxygen environment
Adjustable CO2 concentration
and flow rate depending on applicationCO2 concentration:2.5%-20.0%
CO2flow rate:50m/min〜200ml/min



An evolutionary step in Stage Top Incubator for Microscopes, providing optimally conditioned mixed gas during Live Cell Imaging.
For stable 5% CO2 + 95%Air mixed gas supply
 O2 concentration  1.0%〜Atomospheric concentration
 CO2 concentration     2.5%〜20.0%  2.5%〜20.0%  5%(fixed)
 Control method     PID method      PID method      PID method
Air gas flow /  Output gas flow  0〜200ml/min  50〜200ml/min  160ml/min(fixed)
Input gas pressure  0.1MPa  0.1MPa 0.1MPa
 Outside dimensions  W175×D260×H280  W160×D300×H200  W160×D300×H200
 Weight  6.5kg  5.7kg  4.8kg
 Power source  AC100V〜240V  AC100V〜240V  AC100V〜240V
 Maximum power consumption  100VA  100VA  100VA
