Huvitz 1x C-Mount Adapter BCA-H-1x

Original price was: $USD 600.00.Current price is: $USD 199.00.

-67%

Convert the Huvitz trinocular microscope phototube/head/port to traditional C-Mount type With different built-in reduction lens (1X, 0.63X, 0.5X, 0.35X) for achieving better field of view from microscope trinocular head suitable for 1”, 2/3”, 1/1.8”, 1/2”, 1/2.5”, 1/3” or 1/4” inch CCD or CMOS sensor chips);

Guaranteed Safe Checkout

Huvitz Microscope C-Mount Adapter

Huvitz Microscope C-Mount Adapter

  • Convert the Huvitz trinocular microscope phototube/head/port (have standard 42 mm outer diameter for the insertion end to phototube) to traditional C-Mount type (25.4 mm or 1 inch diameter with 32 threads per inch);
  • With different built-in reduction lens (1X, 0.63X, 0.5X, 0.35X) for achieving better field of view from microscope trinocular head
  • suitable for 1”, 2/3”, 1/1.8”, 1/2”, 1/2.5”, 1/3” or 1/4” inch CCD or CMOS sensor chips);
  • Can be installed in UIS trinocular tube such as : HUVITZ HRM series, HSZ series microscopes
  • Build of material: anodized aluminum; Telecentric optics with low light deficiency;
  • Parfocal with different microscope objective lenses; Diffraction limited MTF;
  • Aperture totally coupled with UIS microscope objective’s exit pupil;

Huvitz  Phototube to C-Mount Adaptor (Huvitz TV Adaptor)

Huvitz Model

Our Catalogue #

HSZ-CP1X

BCA-H-1x

HSZ-CP0.63X

BCA-HS-0.63x

HSZ-CP-0.5X

BCA-HS-0.5x

HSZ-CP-0.35X

BCA-HS-0.35x

Product Picture

Huvitz 0.50x C-Mount Adapter BCA-H-0.5x Huvitz 0.63x C-Mount Adapter BCA-H-0.63x Olympus U TV0.5XC 3 Huvitz 0.35x C-Mount Adapter

Magnification

1X

0.63X

0.5X

0.35X

Sensor Size

1”, 2/3”

2/3”,1/1.8”,1/2”

1/1.8”,1/2”,1/2.5”

1/2.5”,1/3”,1/4”

Microscope

Specially designed for HUVITZ  HRM300 series UprightHSZ series Stereo microscopes

If you need help, please contact us and specify your microscope brand and model and your camera brand, model and chip size (if you know), Bioimager engineers will help you choose the right adaptor magnification;
