MT8100 Meiji Metallurgical Upright Refl & Trans BF Microscope


  • Meiji Techno (Japan) product
  • Metallurgical compound microscope,
  • MTT8000 & MT8100 series
  • Brightfield & Simple polarization
  • with incident (reflected) and transmitted  light,
  • LED or halogen illumination,
  • Bincoular or trinocular head, with optional ergonomic choice
  • 5x, 10x, 20x, 50x, 100x Plan Epi obj lenses
  • infinity corrected optical system F=200mm

$USD 6,521.00 $USD 7,245.00

The new MT8000 Series can be used for a wide range of applications because it uses both incident and transmitted brightfield illumination. Each model has a ceramic coated stage, full Koehler 30W halogen illumination and an attachable mechanical stage with drop down controls.

  • Meiji Techno (Japan) product
  • Metallurgical compound microscope,
  • MTT8000 & MT8100 series
  • Brightfield & Simple polarization
  • with incident (reflected) and transmitted  light,
  • LED or halogen illumination,
  • Bincoular or trinocular head, with optional ergonomic choice
  • 5x, 10x, 20x, 50x, 100x Plan Epi obj lenses
  • infinity corrected optical system F=200mm

MT8000 Meiji Metallurgical Upright Refl & Trans BF Microscope

Meiji Techno MT8000 Upright Reflected & Transmitted BF Metallurgical Microscope

Highlighted Features

  • Upright Microscope
  • Reflected & Transmitted lights
  • Brightfield imaging system
  • Infinity Correcetd Optical Systems
    • Plan Epi BF 5x
    • Plan Epi BF 10x
    • Plan Epi BF 20x
    • Plan Epi BF 50x
  • A pair of SWH 10x/FN22, OD30
  • Stage: Ceramic Coated Flat-top
  • Power Supply: Automatic Voltage Sensing
  • Illumination: Vertical Koehler 6v/30W Haolgen Incident
  • Ergonomic binocular viewing head (optional)

Models:

MT8000  Binocular Seidentopf, Halogen

MT8100 Trinocular  Seidentopf, Halogen

MT8000L  Binocular Seidentopf, LED

MT8100L Trinocular  Seidentopf, LED

MeijiMT/mt8000-01.jpg

The new MT8000 Series can be used for a wide range of applications because it uses both incident and transmitted brightfield illumination. Each model has a ceramic coated stage, full Koehler 30W halogen illumination and an attachable mechanical stage with drop down controls.
The MT8000 Series features include:

  • Computer Aided Design
  • Ergonomically positioned controls
  • Comfortable Siedentopf viewing head
  • 30W Vertical Koehler Illuminator with auto voltage sensing power supply
  • 30W Transmitted Koehler Illuminator with auto voltage sensing power supply
  • Brightfield Reflected Light and Brightfield Transmitted Light observation modes
  • Optional Ergonomic binocular viewing head available

MeijiMT/MT8300.jpg

VIEWING HEADS
Model MA815 is the Siedentopf-type binocular head and Model MA816 is the trinocular head for camera integration. Each head has the eyetubes inclined at 30° with the left eyetube having graduated diopter settings. The interpupillary distance is adjustable between 53mm – 75mm. An 80/20 beamsplitter for the trinocular tube can be engaged for photo work. The optional Ergonomic Viewing Head has the inclination adjustable from 10 to 50 degrees to fit any size user.

MA815Siedentopf type binocular head. 30 degree inclination, 30.0mm ø eyetubes. (MT8000)
MA816Siedentopf type trinocular head. 30 degree inclination, 30.0mm ø eyetubes. (MT8100)
MA957Siedentopf type Ergonomic binocular head. 10 – 50 degree adjustable inclination, 30.0mm ø eyetubes. (optional)
MA979Trinocular head – Siedentopf type, erect image with sliding 0/100 beamsplitter, inclined at 30 degrees, I.P. adjustment 53mm to 75mm, graduated diopter on left eyetube. (optional)

MeijiMT/MT7000_head.jpg

Metallurgical/MT7530_trinohead_300w.jpeg

EYEPIECES
10X Super Widefield High Eyepoint eyepieces F.N.22 are standard, and 15X and 20X eyepieces are available as an option. A Super Widefield High Eyepoint 10X focusable eyepiece that accepts 25mm reticules is also available.

MA817SWH10X Super Widefield High Eyepoint eyepiece, FN22 (standard) (accepts 25mm reticle)
MA818SWH15X  Super Widefield High Eyepoint eyepiece, FN16 (optional) (accepts 19mm reticle)
MA819SWH20X  Super Widefield High Eyepoint eyepiece, FN12 (optional) (accepts 19mm reticle)
MA859SWH10X-F Super Widefield High Eyepoint focusing, FN22 (optional) (accepts 25mm reticle)

MeijiMT/DSCN2720-1.jpg
OBJECTIVE CHANGER
The smooth-operating, ball bearing mounted, quintuple nosepiece provides effortless objective changes.

OBJECTIVES
Meiji Techno offers an assortment of Plan Epi Infinity Corrected objectives for Brightfield work.

Plan Epi * Long Working Distance * Brightfield Objectives – Infinity Corrected – F = 200mm
MA920LWD Plan Epi 20X objective, NA: 0.40, Working Distance = 11.0mm (optional)
MA921LWD Plan Epi 50X, objective, NA: 0.55, Working Distance = 7.5mm (optional)
 Plan Epi Brightfield Objectives – Infinity Corrected – F = 200mm
MA870Plan Epi 5X objective, NA: 0.10, Working Distance = 20.0mm (included)
MA871Plan Epi 10X, objective, NA: 0.25, Working Distance = 7.48mm (included)
MA872Plan Epi 20X, objective, NA: 0.40, Working Distance = 5.2mm (included)
MA873Plan Epi 50X, objective, NA: 0.75, Working Distance = 0.38mm (included)
MA874Plan Epi 100X, objective, NA: 0.90, Working Distance = 0.37mm (optional)

MeijiMT/MT_lenses.jpg
STAGE
Ceramic coated left or right-handed, flat top stage measures 191mm x 126mm with x-y travel: 100mm(X) x 100mm(Y). Ergonomically positioned coaxial drop down controls.



MA942

Ceramic coated flat-top stage, 191mm X 126mm, 100mm X 100mm, X-Y movement, with right hand drop-down coaxial controls and 94.5mm diameter clear glass stage plate. (Included in Model MT8000 and MT8100)

MeijiMT/DSCN2620.JPG

ILLUMINATION
Powerful 30 watt halogen transmitted and incident reflected illumination systems provides enhanced image quality and brightness for the observation of metallurgical specimens.

Metallurgical/MT7000_closeup_500w.jpeg



MeijiMT/ma523.jpgMeijiMT/ma506.jpgMeijiMT/ma542.jpgMeijiMT/ma738.jpgMeijiMT/ma292.jpg
 Cross-line reticle, 25mm diameter10mm divided into 100 units, 25 mm diameter5mm divided into 100 parts, 1.0 mm square, 25mm diameterfor grain sizing in steel, 25mm diameter metal stage micrometer, 0.01mm, for reflected light



Condenser
MA910/05Substage condenser with iris diaphragm, dovetail mount (For MT8000 & MT8500) (included)
Filters
MA497Polarizing filter, 20 mm in-mount (included)
MA475/05Blue clear filter, LB100, 20mm in-mount (included)
MA476Green clear filter, 20mm in-mount (included)
>MA774ND50 Neutral density filter 20mm in-mount (transmission: 50%) (included)
MA857/05Green clear filter for transmitted illuminator, 44mm (optional)
F-V73990Red clear filter in mount for bichromatic mode (optional)



 Misc. Parts & Accessories
MA809/10Replacement 115V AC Power cord with plug (USA)
MA809/20Replacement 220V AC Power cord with plug (Eurocord)
MA809/30Replacement 240V AC Power cord with plug (UK)
MA958Photo/Video attachment with 80/20 beamsplitter, fits MA957 only
MA942Ceramic coated flat top stage with glass plate insert (included)
MA711Dust Cover for MT8000 Series (included)
MA927Vertical Koehler Illuminator 6V 30W Halogen (included)
MA927/05Power Supply for MA927, 100V – 240V (included)
MA326Spare bulb for halogen transmitted illuminator, 6V, 30W
MA327Spare fuse for halogen transmitted or vertical illuminator, 3A
MA906Eyeshield (ea) for MA817 10x eyepieces (included)

MT8000 Series Models

ModelHeadIlluminationEyepiecesObjectivesStage
MT8000Bino.30W Vertical Koehler + 30W Transmitted KoehlerSWH10x FN22Plan Epi 5x, 10x, 20x, 50xCeramic Coated Fixed Flat-top left or right-handed controls
MT8100Trino.

click here to download MT8000 Brochure
