MTCA Meiji Techo C-Mount Adapters


Any digital or video camera with a “C” type lens mount can be mounted on any Meiji Techno trinocular microscope (25.2mm tube) by using these “C”-mount attachments.They are available with projection lenses of different powers allowing some control over the magnification and the field of view. “CS” mount cameras will require part number V-5MM to be threaded on prior to installing the adapter.

$249.00

Meiji Techo C-Mount Adapters (Japan)

Any digital or video camera with a “C” type lens mount (1″ or 25.4mm diameter thread) can be mounted on any Meiji Techno trinocular microscope (25.2mm tube) by using these “C”-mount attachments.

Camera Chip SizeSuggested Adapter
1/4″0.265 or 0.3X
1/3″0.3X
1/2″0.45X, 0.5X or 0.6X
1/1.8″0.45X, 0.5X or 0.6X
2/3″0.7X

They are available with projection lenses of different powers allowing some control over the magnification and the field of view. “CS” mount cameras will require part number V-5MM to be threaded on prior to installing the adapter.

Note: Reduction lenses (i.e. magnification factors less than 1.0x) are commonly used to compensate for the increased magnification factor inherent with cameras used on microscopes.



camera/cmountwlens01.jpgcamera/cmountsCombine.jpg



“C” Mount Adapter Ordering Information
Price: $249
“C” Mounts Without Lenses



MA151/5N“C” Mount Adapter for EMTR, EMZ-2TR, EMZ-5TR, GEMZ-2TR, & GEMZ-5TR – HAS NO LENS (Replaces existing photo tube)
MA151/10“C” Mount Adapter for all Compound Trinocular Microscopes – HAS NO LENS (Replaces existing photo tube)

“C” Mounts With Lenses and Reticle Mounts – For all Meiji Trinocular Compound and Stereo Microscopes (reticle mounts accept 19mm reticle)

MA151/35/03“C” Mount Adapter with 0.30X lens (Slips over existing photo tube)
MA151/35/04“C” Mount Adapter with 0.45X lens (Slips over existing photo tube)
MA151/35/05“C” Mount Adapter with 0.5X lens (Slips over existing photo tube)
MA151/35/15“C” Mount Adapter with 1.0X lens (Slips over existing photo tube)
MA151/35/20“C” Mount Adapter with 0.7X lens (Slips over existing photo tube)
MA151/35/25“C” Mount Adapter with 2.5X lens (Slips over existing photo tube)
MA151/35/50“C” Mount Adapter with 0.5X lens (Slips over existing photo tube)

“C” Mounts for EMZ-8TR, EMZ-8TRD, EMZ-12TR, EMZ-12TRD and EMZ-13TR

MA151/8TR“C” Mount adapter with 0.60X lens (Replaces existing photo tube)
MA151/8TR/02“C” Mount adapter with 0.265X lens (Replaces existing photo tube)

“C” Mount Adapter – For all Meiji TC & IM Series Front Camera Ports on Inverted Microscopes

MA877
C-Mount Adapter for front port IM & TC Series (no lens, port has 0.66x mag factor)
