BM-1LED Meiji Techno Stereo Microscope (Japan)

$USD 735.00

BM and BMK LED Series Long Arm Stereo Microscopes from Meiji Techno are high quality industrial and healthcare quality stereo microscopes mounted on a 255mm horizontal inclinable arm supported by a 300mm vertical post and heavy cast base. The integral illuminators on BM Models feature a three lens condenser system fitted into the binocular body and an AC auto voltage sensing power supply. BMK Model illuminators are mounted on the side with a ball swivel. The paired interchangeable parfocal objectives are mounted on a dovetail slide. Each unit is supplied with a plastic dust cover, grounded power cord and fitted Styrofoam packing.

Free worldwide shipping on all orders over $50

  • 30 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

BM and BMK LED Series Long Arm Stereo Microscopes from Meiji Techno are high quality industrial and healthcare quality stereo microscopes mounted on a 255mm horizontal inclinable arm supported by a 300mm vertical post and heavy cast base. The integral illuminators on BM Models feature a three lens condenser system fitted into the binocular body and an AC auto voltage sensing power supply. BMK Model illuminators are mounted on the side with a ball swivel. The paired interchangeable parfocal objectives are mounted on a dovetail slide. Each unit is supplied with a plastic dust cover, grounded power cord and fitted Styrofoam packing.

Meiji Techno BM-2LED Stereo Microscope (Japan)

The BM Series features include:

  • Upright stereoscopic images
  • High Quality optics with long working distance
  • Integral LED spot illuminator aligned with optical axis
  • Rated for 30,000 hours
  • Cool lighting
  • Auto voltage sensing
  • Magnification range 2.5X to 70X with optional lenses
  • Interpupillary distance 51mm to 80mm
  • Paired interchangeable parfocal objectives with quick-change dovetail slide mount

Please note: BM and BMK objectives are not interchangeable

Model Objective Eyepieces Magnifications Illuminatior
BM-1LED 1X and 2X WF10X 10X and 20X High Intensity LED
BM-2LED 1X, 2X and 3.5X 10X, 20X and 35X

Meiji Techno BM-2LED Stereo Microscope (Japan)
Meiji Techno BMK-1/LED Stereo Microscope (Japan)
Meiji Techno BM-2LED Stereo Microscope (Japan)
Meiji Techno BM-2LED Stereo Microscope (Japan)
Meiji Techno BM-2LED Stereo Microscope (Japan)

OPTIONAL COMPONENTS & ACCESSORIES BELOW

Eyepieces
MA101: Widefield eyepieces 5X (paired), FN:22
MA102: Widefield eyepieces 10X (paired), FN:20 with 25mm reticle mount
MA103: Widefield eyepieces 15X (paired), FN:13 with 25mm reticle mount
MA104: Widefield eyepieces 20X (paired), FN:11 with 25mm reticle mount

Objectives for BM Series
MA113: Paired objective 0.5X for BM 40mm with WF10X 106mm
MA106: Paired objective 1X for BM 20mm with WF10X 170mm
MA107: Paired objective 2X for BM 10mm with WF10X 107mm
MA109: Paired objective 3.5X for BM 7mm with WF10X 70mm

Note: BM & BMK objectives are not interchangeable
